Patent-Filed Innovation · Make in India
Breathe Clean · Live Healthy

India's First
4-Stage Open Ambient
Air Purification System

MAAPS — Advanced Multi-Stage Technology for Continuous Air Purification in Open Ambient Spaces. Engineered in Delhi, built for India's toughest air quality challenges.

SEE THE PRODUCTVIEW PERFORMANCE
>99.5%
PM2.5 Removal
>80%
Indigenous Content
4
Purification Stages
MAAPS · Airflow Architecture
⬇ Polluted Ambient Air Inlet
🌫️
Stage 01
Pre-Filtration
G4 + F7 + HEPA H13 · Removes PM10 & PM2.5
↓
⚡
Stage 02
Electrostatic Precipitator
12–14 kV ionization · Captures Fine & Ultrafine Particles
↓
🔬
Stage 03
UV Germicidal Irradiation
253.7 nm UV-C · Destroys Bacteria, Viruses & VOCs
↓
✨
Stage 04
Negative Ionizer
>10M ions/cm³ · Neutralizes & Removes PM0.3 & Below
⬆ Clean Air — Better Life
MAAPS · Complete Product Overview

Saaphzone Air Purifier — For Ambient Environment

Saaphzone MAAPS Air Purifier — Complete Product Overview for Ambient Environment
📞9882810053
✉️sales@saaphzone.com
🌐www.saaphzone.com
🇮🇳Made in India
The Crisis We Solve

Delhi's Air Is Not an Inconvenience. It's an Emergency.

Every winter, Delhi's PM2.5 levels breach 500 µg/m³ — over 100× the WHO guideline. Conventional indoor purifiers cannot function outdoors. No single-stage technology addresses the full spectrum simultaneously.

WHO Annual Guideline5 µg/m³
India NAAQS Standard40 µg/m³
Delhi Winter PM2.5 (Peak)500+ µg/m³
Why Existing Solutions Fall Short
🏠
Indoor Air Purifiers
Require enclosed chambers. Useless in parks, bus stops, and open streets where pollution exposure is highest.
💧
Water-Mist Cannons
Temporary suppression only. Do not address PM2.5, ultrafine particles, biological agents, or VOCs.
🏗️
Industrial Smog Towers
Cost-prohibitive, infrastructure-heavy, not optimized for Indian meteorological conditions.
❌
No Integrated Outdoor Solution
No prior patent in India combines Pre-Filter + ESP + UV-C + Negative Ionizer in one compact outdoor unit.
Four-Stage Architecture

Every Pollutant. One System.

MAAPS integrates four sequential purification technologies in a single compact housing — a first for open ambient outdoor deployment in India.

STAGE 01
🌫️
Pre-Filtration System
A tri-layer filter cassette forms the first line of defence. G4 polypropylene coarse filter intercepts PM10. F7 micro-glass fibre filter captures the 1–10 µm range. HEPA H13 layer achieves 99.97% efficiency at 0.3 µm — protecting downstream stages and extending maintenance intervals. Front-loading, tool-free cassette allows rapid on-site replacement.
HEPA H13 · EN1822G4 + F7 Layers99.97% @ 0.3µm80–150 Pa Resistance
STAGE 02
⚡
Electrostatic Precipitator (ESP)
A 12–14 kV corona discharge ionizer charges all passing aerosol particles. Alternating high-voltage (6–8 kV) and grounded aluminium collector plates capture them electrostatically with >95% efficiency. An automated motorized wiper self-cleans collector plates on a programmable schedule — eliminating frequent manual maintenance for outdoor deployments.
12–14 kV Ionizer>95% CollectionSelf-Cleaning ESPSS316 Electrodes
STAGE 03
🔬
UV Germicidal + TiO₂ Photocatalysis
UV-C lamps at 253.7 nm deliver minimum 40 mJ/cm² dosage — achieving log-4 (99.99%) inactivation of bacteria, viruses, and mould spores. A TiO₂ photocatalytic honeycomb substrate decomposes formaldehyde, benzene, toluene, NOx, and VOCs through photocatalytic oxidation.
253.7 nm UV-C99.99% Pathogen KillTiO₂ Photocatalyst<0.05 ppm Ozone
STAGE 04
✨
Negative Ion Generator
A carbon fibre brush array emits over 20 million negative ions per cm³/second, attaching to ultrafine PM0.3 particles in surrounding air. Charged particles agglomerate and settle — effectively cleaning a 5+ metre radius around the unit.
>20M ions/cm³/s5m Ambient Radius3–5W Per Module<0.02 ppm Ozone
Verified Performance

Numbers That Define Clean Air

Every specification reflects tested and validated operating parameters across all four stages in combined configuration.

>99.5%
Efficiency
PM2.5 Removal
500
m³ / hour
Min. CADR
>99.99%
Log-4 Kill
Pathogen Reduction
200m²
Outdoor Zone
Max. Coverage
ParameterSpecification
PM10 Removal (In-duct)>99.9%
PM2.5 Removal (In-duct)>99.5%
Bacteria/Virus Kill Rate>99.99% (log-4)
VOC Decomposition>70%
Negative Ion Output>10M ions/cm³
Clean Air Delivery Rate500 m³/hr min.
Effective Outdoor Coverage50–200 m²
Max Power Consumption300 W
Eco Mode Power80 W
Noise Level (Max Speed)<55 dB(A) @ 1m
Ingress ProtectionIP54 / IP65 option
Operating Temperature–5°C to +50°C
Ozone at Outlet<0.05 ppm
ESP Collection Efficiency>95% @ >0.3µm
Saaphzone AirControl Platform

Smart Monitoring. Real-Time Air Quality Data.

Every MAAPS unit ships IoT-ready with Wi-Fi and 4G/LTE connectivity, feeding live air quality data to the Saaphzone AirControl mobile app.

📡
Live PM2.5 / PM10 Monitoring
Laser particle counter measures inlet and outlet concentrations continuously, tracking purification efficiency in real time.
⚙️
Adaptive Fan Speed Control
PWM-controlled EC brushless fans auto-adjust based on ambient AQI — maximum power when pollution peaks, eco mode when air clears.
🔔
Predictive Maintenance Alerts
Filter life tracking, ESP plate cleaning reminders, UV lamp counters, and fault diagnostics pushed to the app before issues arise.
🏭
Industrial Integration via Modbus
RS-485 Modbus RTU enables seamless integration with SCADA systems, smart city dashboards, and CPCB monitoring networks.
Saaphzone AirControl
● LIVE
28
AQI
✅ Air Quality : GOOD
12
PM2.5 µg/m³
18
PM10 µg/m³
26°
Temp/58%RH
System Status
Stage 1 Pre-Filter : ✅ Operating
Stage 2 ESP : ✅ 12.4 kV Active
Stage 3 UV-C : ✅ 9,240 hr lamp
Stage 4 Ionizer : ✅ Ions Active
Wide Applications

Built for India's Most Polluted Spaces

Available in wall-mount, pole-mount, and standalone pedestal configurations with IP54 weather protection — ready for immediate outdoor deployment across India.

🎓
Schools
Ensure healthy air for our future generation. Protecting children during outdoor breaks, sports, and morning assemblies.
🏥
Hospitals
Cleaner air for faster recovery and well-being. Protecting immunocompromised patients at OPD areas, emergency entrances, and outdoor waiting zones.
🚆
Railway Stations
Purifying air in high-footfall public areas. Continuous clean air across platforms and commuter concourses.
🌳
Parks & Gardens
Clean, fresh air for recreation and relaxation. Enabling safe outdoor leisure during high-pollution winter months.
🚌
Bus Stands & Terminals
Improved air quality in crowded areas. Reducing PM exposure for commuters.
🛒
Markets & Commercial Areas
Cleaner air for vendors and shoppers at open-air markets and commercial complexes.
Make in India • Atmanirbhar Bharat
Indigenous Manufacturing

Designed in Delhi. Built for Bharat.

MAAPS is conceived, engineered, and manufactured entirely in India by Saaphzone Technologies LLP. Every component — from MS housing fabricated in Faridabad to PCBs designed by Saaphzone and made in Noida — reflects a deliberate commitment to Indigenous supply chains under Make in India and Atmanirbhar Bharat initiatives.

With over 80% indigenous content by value, MAAPS is registered under the Small Entity / Startup category per DPIIT guidelines and qualifies for government procurement preferences.

>80%
Indigenous Content
100%
Housing & Frame
DPIIT
Startup Recognised
ComponentIndian Source%
MS/SS Housing & FrameFaridabad / Delhi NCR100%
Filter Media (G4, F7)Gujarat / Maharashtra100%
ESP Aluminium PlatesDelhi NCR / Ludhiana100%
UV-C LampsHalonix / Havells India100%
HVPS PCB (ESP)Noida / Bengaluru90%
UV Ballast PCBPCB Fab, Noida85%
IoT ControllerAssembled in India85%
EC Axial FansIndian Motor OEM80%
Overall SystemSaaphzone LLP, Delhi>80%
Patent Application Filed · India

A Novel, Patented Architecture for Outdoor Air Purification — First of Its Kind in India

Conceived and filed by Dr. Vivek Prakash Pankaj, Partner, Saaphzone Technologies LLP — with no equivalent found in Indian, US, or European patent databases.

Open Ambient Operation - No Enclosure Required4-Stage Integration in Single UnitSelf-Cleaning Outdoor ESPIoT-Integrated Air Quality Reporting10 Patent Claims Filed
